Blackmagic Design Studio Camera 6K Pro (EF Mount) (Body Only)
GH₵65,840.00
Product Highlights
- NB *LENS NOT INCLUDED*
- Active Canon EF Lens Mount
- Capture up to 6K 6144 x 3456p50
- Live Streaming
- Remote Controlled ND Filters
- Raw Recording to External USB-C Disks
- Records Blackmagic Raw, Up to 25,600 ISO
- 7" High-Brightness HDR Touchscreen LCD
- 12G-SDI, HDMI & 10G Ethernet Video IO
- XLR & 3.5mm Audio Input, Built-In Mics
- Built-In DaVinci Resolve Color Corrector
Specs
Blackmagic Design Studio Camera 6K ProSpecs
Imaging
| Sensor Resolution | Not Specified by Manufacturer |
| ISO Sensitivity | 100 to 25,600 |
| Gain | 0 to 18 dB |
| Sensitivity | f11 at 2000 lux 89.9% Reflectance (UHD 4K60) f12 at 2000 lux 89.9% Reflectance (UHD 4K60) |
| Signal-to-Noise Ratio | 63 dB |
Camera
| Lens Mount | Canon EF Mount |
| Shutter Speed | 15000 to 124 Second |
| Built-In ND Filter | Mechanical Filter Wheel with Clear, 2-Stop (14), 4-Stop (116), 6-Stop (164) ND Filters |
| Built-In Microphone Type | Stereo |
| Broadcast System Compatibility | NTSC, PAL |
Interfaces
| CCU IO | None |
| Video IO |
1 xBNC (12G-SDI) Input 1 xBNC (12G-SDI) Output 1 xHDMI Output |
| Audio IO |
2 xXLR 3-Pin MicLine (+48 V Phantom Power) Input on Camera Body 1 x18" 3.5 mm TRS Stereo Microphone Input 1 x18" 3.5 mm TRRS HeadphoneMic InputOutput 1 xXLR 5-Pin Intercom InputOutput |
| Other IO |
1 xRJ45 (10 Gigabit Ethernet) ControlDataMonitorVideo InputOutput 2 xUSB-C (USB 3.2 3.1 Gen 1) DataVideo InputOutput |
Recording
| Raw Recording |
Blackmagic RAW 10-Bit 6144 x 3456 up to 50 fps 5376 x 3024 up to 60 fps 3840 x 2160 up to 60 fps |
| Audio Recording | ProRes 2-Channel 24-Bit 48 kHz LPCM Audio |
Display
| Display Type | Fixed Touchscreen LCD |
| Size | 7" |
| Resolution | 1920 x 1200 |
Power
| Power IO |
1 xXLR 4-Pin (12VDC) Input 1 xBarrel (12VDC) Input |
| Power Consumption | 59 W |
Environmental
| Operating Temperature | 32 to 104F 0 to 40C |
| Storage Temperature | -4 to 113F -20 to 45C |
| Operating Humidity | 0 to 90% |
General
| Accessory Mount | 2 x14"-20 Female |
| Tripod Mount | 38"-16 Female |
| Dimensions (W x H x D) | 10.77 x 7.83 x 6.59" 27.36 x 19.89 x 16.74cm (Without Protrusions) |
| Weight | 4.28lb 1.94kg |
